The CSP family consists of four models, which differ in the number of zones (supervised lines), programmable outputs and the way in which information about the system status is presented.
Selection of a model depends on the size of the facility and operation method.
We offer all the necessary devices required to set up a fire alarm system: manual call points (suitable for indoor and outdoor installation), automatic smoke detectors, heat detectors and multisensor detectors. This way the security level can be individually adapted to protected facility.
Our Fire Alarm System (FAS) meets the stringent safety standards of the EN 54 guidelines. It is managed by the CSP panels, equipped with easy to read front panel for convenient system operation.
CPS control panels have two non-volatile memories. The first one can store a log of up to 8 999 different events (and alarms), while the other can store up to 9 999 alarms. Facility administrators can export stored data to various popular file formats (like CSV and more). These might be helpful when determining causes of operating system errors.
The system can also be operated via PSP Remote Operation and Signalling Devices (up to 1 km away from the main CSP panel). These devices, installed in security buildings or other locations provide access to all system functions and its status. The latter can also be monitored via Virtual PSP repeater panel, when connected with a CSP-ETH Ethernet module.
Dust and dirt may interfere with the proper functioning of smoke detectors, as well as smoke and heat detectors, and trigger false alarms. That is why all the SATEL detectors are equipped with a system detecting contamination of measuring chambers. Contamination is signalled by LEDs, and requires a service call.
The CSP control panels feature a number of well-designed solutions, which facilitate periodic system inspections and maintenance. The service mode is protected by a password, entered via keypads on the front panels. Therefore there is no need to open the control panel enclosure in order to change its configuration. Additionally, the detector testing mode can be performed by a single person only, which in turn reduces the number of people required to efficiently verify the installations.
Features | CSP-200 Series | CSP-100 series | ||
|---|---|---|---|---|
| CSP-208 | CSP-204 | CSP-108 | CSP-104 | |
| Number of supervision zones | 8 | 4 | 8 | 4 |
| Number of alarm outputs | 2 | 2 | 2 | 2 |
| Outputs to Fire Alarm trasmission devices/Fault transmissions devices | yes/yes | yes/yes | yes/yes | yes/yes |
| Number of programmable inputs | 4 | 4 | 4 | 4 |
| Number of programmable outputs | 8 | 4 | 8 | 4 |
| Display for easy operation | yes | yes | no | no |
| Compatibility with remote repeater panel | yes | yes | yes | yes |
| Compatibility with virtual panel | yes* | yes* | yes* | yes* |
| AUX (12-18 V) power supply | yes | yes | yes | yes |
| AUX24 (24 V) power supply | yes | yes | yes | yes |
| Event memory capacity | 8999 | 8999 | 8999 | 8999 |
| Alarm meter capacity | 9999 | 9999 | 9999 | 9999 |
* Function requires connection of CSP-ETH module
